Saramonic SR-Q2 Portable Field Audio Recorder

The Saramonic SR-Q2 is a handheld audio recorder with a built-in X/Y stereo microphone. The easy-to-read LCD menu display and onebutton-recording interface make SR-Q2 very simple to use. Ideal for using in applications such as audio for video, ENG, filmmaking, field recording, music production, podcasting, etc.

The X/Y microphone captures clean stereo sound. The integrated flash recording allows you to record up to 96kHz/16bit. wav audio files to a microSD card of capacity up to 32GB or a microSDXC card of capacity up to 128GB. Separate microphone input and line input jacks provide a multitude of options for attaching a wide range of audio equipment.

Recording channel: 2
Recovery channel: 2
Recording format .WAV
(44.1kHz/16bit, 44.1kHz/24bit, 48kHz/16bit ,
48kHz/24bit, 88.2kHz/16bit, 96kHz/16bit)
Playback format: .WAV
(44.1kHz/16bit, 44.1kHz/24bit, 48kHz/16bit,
48kHz/24bit, 88.2kHz/16bit, 96kHz/16bit)
A/D conversion: 24-bit, 128x oversampling
D/A conversion: 24-bit, 128x oversampling
Signal processing 32-bit
Recording media: Micro SD card (8-32GB)
MicroSDXC (64-128GB)
LCD: LCD 128*64 ( with light )
Built-in stereo mic: 90° X/Y stereo configuration
Unidirectional condenser
Minimum gain with digital attenuation: -30dB
Microphone Input: 3.5mm (1/8”) Stereo Microphone Input
Line Input: 3.5mm (1/8”) Line Level Input
Input level: 0 to -45dB
Output impedance: 2 kΩ
Line output: 3.5mm (1/8) stereo jack
Output load impedance: 10 kΩ or more
Rated output level: -10dBm
Headphone output level: 20mW 20mW into 32Ω load
Built-in Speaker: 1W 8Ω
USB jack: Type-C
Power required: LR6 or Ni-MH AA battery X 2
USB DC 5V
Recording hours: Alkaline Battery
13.5 hours under 96kHz/16bit (wav)
19.5 hours under 44.1kHz/16bit (wav)
Weight: 116g (4.1oz.)
Dimension: 60 (W) x 167 (D) x 30 (H) mm
