Description
Barix Instreamer ICE IP Audio Encoder/Server
The Instreamer ICE encodes analog audio into MP3 or AAC for streaming to an Icecast or Shoutcast internet radio streaming service in the cloud. The Instreamer ICE also has an Icecast server built in and is able to feed up to 50 web radio listeners directly without the requirement to subscribe to an internet radio service provider.
Applications
- Live IP Audio Encoder for Streaming Applications
Shoutcast/Icecast Source Encoder
Features
- MP3 and AAC+ encoding
- Stream authentication
- Icecast source mode
- Stream Relay
- Streams to Icecast internet radio service
- Integrated Icecast streams to 100 simultaneous listeners without radio service
- Line input (stereo)
- Supply voltage 5VDC
Power Supply Input
• External power adaptor, 100-240VAC, 10W
• Male connector: 5,5 x 2,1 mm
1 Ethernet Interfaces
• RJ45 10/100 auto detect, IPv4, IPv6
Audio Input
• Stereo RCA / cinch connectors
Audio formats
• MP3, AAC mono and stereo
• Sample rates 22.05/24/32/44.1/48Khz
Headphone output
• Female Jack 3.5 mm
USB
• Double USB connector type A female
(for future use)
RS-232
• For meta data contribution
Icecast
• Integrated Icecast server:
supports up to 50 subscribers
• Source to external Icecast server
HW/SW environment
• Barix IPAM400
• Linux with dual boot recovery and remote firmware update capability
User Interface
• Web interface for control, status and configuration
• HW reset button, LEDs for status
Case & Weight
• Aluminum
• 108x38x78.7mm (4.25×1.5×3.1 inch)
• Weight 250g
MTBF
• >199’951 h / > 22 years
Warranty
• Warranty: two years
- Discription
-
Barix Instreamer ICE IP Audio Encoder/Server
The Instreamer ICE encodes analog audio into MP3 or AAC for streaming to an Icecast or Shoutcast internet radio streaming service in the cloud. The Instreamer ICE also has an Icecast server built in and is able to feed up to 50 web radio listeners directly without the requirement to subscribe to an internet radio service provider.
Applications
- Live IP Audio Encoder for Streaming Applications
Shoutcast/Icecast Source Encoder
Features
- MP3 and AAC+ encoding
- Stream authentication
- Icecast source mode
- Stream Relay
- Streams to Icecast internet radio service
- Integrated Icecast streams to 100 simultaneous listeners without radio service
- Line input (stereo)
- Supply voltage 5VDC
- Live IP Audio Encoder for Streaming Applications
- Specifications
-
Power Supply Input
• External power adaptor, 100-240VAC, 10W
• Male connector: 5,5 x 2,1 mm1 Ethernet Interfaces
• RJ45 10/100 auto detect, IPv4, IPv6Audio Input
• Stereo RCA / cinch connectorsAudio formats
• MP3, AAC mono and stereo
• Sample rates 22.05/24/32/44.1/48KhzHeadphone output
• Female Jack 3.5 mm
USB
• Double USB connector type A female
(for future use)RS-232
• For meta data contributionIcecast
• Integrated Icecast server:
supports up to 50 subscribers
• Source to external Icecast serverHW/SW environment
• Barix IPAM400
• Linux with dual boot recovery and remote firmware update capabilityUser Interface
• Web interface for control, status and configuration
• HW reset button, LEDs for statusCase & Weight
• Aluminum
• 108x38x78.7mm (4.25×1.5×3.1 inch)
• Weight 250g
MTBF
• >199’951 h / > 22 years
Warranty
• Warranty: two years
