AEV Matrix 4×4 Stereo Audio Matrix Switcher

Explore unparalleled audio distribution capabilities with the AEV Matrix 4×4, a cutting-edge solution for seamless audio management. This high-performance audio distributor empowers you to route and control audio signals with precision and efficiency.

Designed to meet the demands of professional audio environments, the Matrix 4×4 boasts a robust 4-input, 4-output configuration, providing versatility for various setups. Whether you’re in a broadcast studio, conference room, or live event space, this device ensures optimal audio routing, enhancing your overall audio production.

One standout feature is the user-friendly interface, making it easy to configure and adapt to your specific audio distribution needs. With AEV’s commitment to quality, the Matrix 4×4 ensures reliable and clear audio transmission, minimizing signal loss and interference.

Experience the convenience of streamlined audio management and elevate your production workflow with the AEV Matrix 4×4. From its durable construction to its advanced features, this audio distributor is a must-have for professionals seeking top-notch performance in audio distribution. Upgrade your audio setup today and witness the difference with AEV’s Matrix 4×4.

Features

• 4 Balanced Analog Stereo Inputs
  4 Balanced Analog Stereo Outputs
  Digital AES/EBU Inputs (Optional)
  Digital AES/EBU Outputs (Optional)
  RGB Key to input & input selection
  Digitally Outputs Level Adjust
  DSP powered
  Software Ethernet control
  Connectors Audio TRS, RJ45
  Display input/output level adjust

Inputs
Input configuration Electronic balanced
Input Impedance 10 KΩ
Input Max Level +20 dBm
Input Level Range -24 ÷ +24 dBm, 1 dB steps
Connector Jack stereo 6,3/XLR*
Digital input (internal plug option)
Input configuration AES/EBU, IEC958, S/PDIF & EIAJ CP340/1201
Sample Rate Automatic 32, 44.1, 48, 96 KHz converter

Outputs
Output configuration Electronically balanced
Output Impedance 50 Ω
Output Max Level +20 dBm
Output Level Range -24 ÷ +24 dBm, 1 dB steps
Connector Jack stereo 6,3 (*optional TRS-XLR adapter)
Digital output (internal plug option)
output configuration AES/EBU, IEC958,S/PDIF & EIAJ CP340/1201
Sample Rate 32, 44.1, 48, 96 KHz converter

General Specifications
Stereo Separation degradation < 1 dB
Distortion @ 1 KHz < 0.01%
Signal to noise ratio < 85 dB (CCIR)
Power requirement 90 – 264 V ~ 50 – 60 Hz
Consumption 20 W
Power supply max power 35 W
Dimension (WxHxD) 48,3 x 19,4 x 4,4 cm 1 rack unit
Weight 2,5 Kg. (5.5 Lbs)
Operating Temp. 0 ÷ 50° C.
